House Plan 1295: The Dillon

The romance and appeal of the Alpine chalet have remained constant over time. With more than 1,500 sq. ft. of living area, this chalet would make a great full-time home or vacation retreat. The L-shaped living room, dining room and kitchen flow together for casual living.  Read more >

House Plan Details

Sq. Ft.
1,536
Beds
3
Baths
2.0
Stories
2
Garages
0
Width
30' 0"
Depth
32' 0"
1st Floor
960
2nd Floor
576
Lower
530
Garage
200
Select Plan Package
Five Sets
$604
$0
Optional Add-Ons
Subtotal: $0

PLAN IMAGES

Upper Floor Plan

Upper Floor Plan
© copyright by designer

Plan Details

Basic Information
Bedrooms: 3
Bathrooms: 2.0
Garage: 0
Stories: 2
Exterior Style
Beach
Contemporary
Cottage
Country
Dimensions
Width: 30' 0"
Height: 30' 0"
Depth: 32' 0"
Heated Living Space
Total Sq. Ft: 1,536
1st Floor: 960
2nd Floor: 576
Lower: 530
Unheated Living Space
Garage: 200
Deck: 125
Ceiling
Upper Ceiling Ft:
Main Ceiling Ft:
Framing Information
Framing: 2x6
Roof Framing: Stick
Bedroom Features
Kitchen Features
Additional Room Features
Garage Location
Front
Garage Features
Attached
Drive-under
Lot Features
Suited for narrow lot
Roof Pitch

Our Guarantee

  • Only the highest quality plans
  • Int’l Residential Code Compliant
  • Full structural details on all plans
  • Best plan price guarantee
  • Free modification Estimates
  • Builder-ready construction drawings
  • Expert advice from leading designers
  • PDFs NOW!™ plans delivered in minutes
  • 100% satisfaction guarantee
  • Free Home Building Organizer

Questions & Answers

Have questions about this plan?
