House Plan 4690: HORSESHOE BAY

This spacious traditional home design is perfect for that difficult corner lot with a rear view. The angled foyer is flanked by the formal dining room and a study. Through the gallery awaits the family, breakfast and kitchen entertaining area. The island kitchen has plenty of room for preparing a special meal. The master suite is situated at the rear of this luxurious home with plenty of privacy and views.  Read more >
Click to Zoom In on Floor Plan
Floor Plans
© copyright by designer
Plan Packages
 Select Plan Package

PDF Single Build


Digital plans emailed to you in PDF format that allows for printing copies and sharing electronically with contractors, subs, decorators, and more. This package includes a license to build the home one time.

PDF Single Build
Most recommended package
$1,160

5 Printed Sets


Five Printed Sets of Residential Construction Drawings are typically 24” x 36” documents and come with a license to construct a single residence shipped to a physical address. Keep in mind PDF Plan Packages are our most popular choice which allows you to print as many copies as you need and to electronically send files to your builder, subcontractors, etc.

5 Printed Sets
Five printed sets of house plans
$1,360

CAD Single Use


2D electronic computer files, completely editable, for design professional use, when making extensive modifications or in the event engineering is required in the area where you are building.

CAD Single Use
2D electronic editable computer files
$1,745
 Need To Reverse This Plan? (Optional)

Readable Reverse


Reverse house plans with readable text and dimensions

Readable Reverse
Reverses house plans with readable text and dimensions
$150
 Select Foundation Option
 Add-Ons (Optional)
Subtotal:
$0
Free Shipping
Features:
View All Plan Features
Kitchen features
Kitchen Island
Nook / Breakfast Area
Peninsula / Eating Bar
Walk-in Pantry
Bedroom features
Double Vanity Sink
Guest Suite
Master Bdrm Main Floor
Separate Tub and Shower
Split Bedrooms
Walk-in Closet
Lot features
Suited for corner lot
Suited for view lot
Additional features
2 Story Volume
Arches
Bonus Room
Dining Room
Family Room
Fireplace
Foyer
Home Office
In-law Suite
Laundry 1st Fl
Vaulted Ceilings
Garage Location
Front
Garage Features
Attached
Front-entry

Hide Plan Features
Details:
View All Plan Details
4,546 Ft
2
Total Structure:
3,043 Ft
2
Total Heated:
2,653 Ft
2
1st Floor:
390 Ft
2
2nd Floor:
3
Bedrooms:
3.5
Bathrooms:
3
Garage:
2
Stories:
76' 0"
Width:
70' 0"
Depth:
35' 5"
Height:
11
Main Floor Ceiling:
10
Upper Floor Ceiling:
2x4
Framing:
Stick
Roof Framing:
12
Primary Roof Pitch:
18
Secondary Roof Pitch:
24
Porch Roof Pitch:
Single
Dwelling Number:
Unheated Living Space
868 Ft
2
Garage:
51 Ft
2
Porch:
143 Ft
2
Patio:
441 Ft
2
Bonus Room:
Exterior Styles
European
Traditional
Collections
Architects Choice
Open Floor Plan
Split Bedroom

Hide Plan Details
Best Price Guarantee

If you find the same house plan (modifications included!) and package for less on another site, show us the URL and we'll give you the difference plus an additional 5% back.

100% Satisfaction Guarantee

We offer a one-time, 14-day exchange policy for unused, non-electronic plan packages in the event you aren't satisfied with your first selection.
