House Plan 8545: Rayleigh

Custom crafted, carriage garage doors (complete with fanlights) and cedar shingle siding encase this finely crafted structure, which holds a second-story, vaulted studio (with bathroom, utility/kitchen area and storage space) and a two-car garage.
