Hudson Carriage House, THD-7123

Sq Ft
750 FT²
Bed
1
Bath
1
Stories
2
Garage
3
Depth
24'
Width
38'
From
$1,045.00
© copyright by designer
View All 2 Images | Photographs may reflect modified home
Sq Ft
750 FT²
From
$1,045.00
Bed
1
Bath
1
Stories
2
Garage
3
Depth
24'
Width
38'

Click to Zoom In on Floor Plan
© copyright by designer



About This Plan

The Hudson Carriage House is a 3 car garage with a 750 sq. ft. studio above. With siding exterior reminiscent of a country barn, this plan would be perfect temporary quarters during construction of your permanent home. Or it would be ideal for an in-law apartment, nanny quarters, college student apartment, etc. This design features an eat-in kitchen, a spacious family room, a bathroom and a bedroom with a roomy closet The laundry appliances are tucked beneath the stairs on the garage level with an optional laundry chute on the living level.


FEATURES & DETAILS

Exterior features
No Porch
Foundation Options
Slab
Lot Options
Suited for narrow lot
Garage Location
Front
Garage Options
Detached
Front-entry
1,608 Ft
2
Total Structure
750 Ft
2
Total Heated
750 Ft
2
2nd Floor
1
Bedrooms
1
Bathrooms
3
Garage
2
Stories
38' 0"
Width
24' 0"
Depth
24' 8"
Height
8'-0"' 0"
Main Floor Ceiling
9'-0"' 0"
Upper Floor Ceiling
2x4
Framing
Stick
Roof Framing
12/12
Primary Roof Pitch
12/12
Gable Roof Pitch
Garage
Dwelling Number
None
Bonus Access

Unheated Living Space
858 Ft
2
Garage


Plan Package Options

 Select Plan Package
$745
PDF Bid Set
PDFs NOW!™

Home plans stamped "NOT FOR CONSTRUCTION" for cost estimating and bidding purposes only; a minimum 5 set plan package must be purchased within 90 days for a license to build plan set; a credit will be applied towards your house plan upgrade

$745
$1,045
PDF Single Build
PDFs NOW!™

Digital plans emailed to you in PDF format that allows for printing copies and sharing electronically with contractors, subs, decorators, and more. This package includes a license to build the home one time.

$1,045
$1,045
5 Printed Sets

Five Printed Sets of Residential Construction Drawings are typically 24” x 36” documents and come with a license to construct a single residence shipped to a physical address. Keep in mind PDF Plan Packages are our most popular choice which allows you to print as many copies as you need and to electronically send files to your builder, subcontractors, etc.

$1,045
$1,195
8 Printed Sets

Eight Printed Sets of Construction Drawings, typically 24” x 36” documents, with a license to construct a single residence shipped to your physical address. PDF Plan Packages are our most popular choice which allows you to print as many copies as you need and to electronically send files to your builder, subcontractors, bank/mortgage reps, material stores, decorators and more.

$1,195
$1,495
CAD Single Build

2D electronic computer files, completely editable, for design professional use, when making extensive modifications or in the event engineering is required in the area where you are building.

$1,495
 Need To Reverse Plan? (Optional)
$295
Readable Reverse

Reverse house plans with readable text and dimensions

$295
  Select Foundation Option
  Add-Ons (Optional)

Free Ground shipping within the Continental U.S.

FREE

Design consultation with the architect or designer to discuss your plan

Home Building Organizer & Product Ideas Binder for Your New Home

Sub Total
$0
Free Shipping
QUESTIONS OR NEED HELP ORDERING? LIVE CHAT OR CALL US AT 866-214-2242
Plan Packages

Each set of construction documents includes detailed, dimensioned floor plans, basic electric layouts, cross sections, roof details, cabinet layouts and elevations, as well as general IRC specifications. They contain virtually all of the information required to construct your home. The typical plan set does not include any plumbing, HVAC drawings, or engineering stamps due to the wide variety of specific needs, local codes, and climatic conditions. These details and specifications are easily obtained from your builder, contractor, and/or local engineers.
