House Plan 5846: Chamblee

Bay windows add light to this small drive under garage ranch plan and help maximize space. Dining, breakfast and master all take advantage of that little bit of extra space making each space more comfortable to furnish. A washer/dryer closet in the hall keeps one from climbing stairs with loads of laundry.  Read more >

House Plan Details

Sq. Ft.
1,667
Beds
3
Baths
2.0
Stories
1
Garages
2
Width
54' 0"
Depth
30' 0"
1st Floor
1,667
Lower
800
Garage
835
Porch
224
Select Plan Package
PDF File
$975
Select Foundation Options
$0
WALK OUT BASEMENT
$0
Optional Add-Ons
Subtotal: $625

PLAN IMAGES

Lower Level

Lower Level
© copyright by designer

Plan Details

Basic Information
Bedrooms: 3
Bathrooms: 2.0
Garage: 2
Stories: 1
Exterior Style
Country
Farm House
Ranch
Dimensions
Width: 54' 0"
Height: 18' 0"
Depth: 30' 0"
Heated Living Space
Total Sq. Ft: 1,667
1st Floor: 1,667
Lower: 800
Unheated Living Space
Garage: 835
Porch: 224
Deck: 168
Ceiling
Upper Ceiling Ft:
Main Ceiling Ft: 8
Framing Information
Framing: 2x4
Roof Framing: Stick
Bedroom Features
Double Vanity Sink
His and Hers Master Closets
Walk-in Closet
Kitchen Features
Nook / Breakfast Area
Walk-in Pantry
Additional Room Features
Dining Room
Fireplace
Foyer
Laundry 1st Fl
Vaulted Ceilings
Garage Location
Under
Garage Features
Attached
Drive-under
Lot Features
Suited for sloping lot
Roof Pitch
Primary: 6/12
