12CANYON RIDGE®carriage houseBeautiful and unique, Canyon Ridge® Carriage House garage doors are constructed with an energy-efficient, Intellicore® polyurethane insulatedsteel base and topped with faux wood overlays. The appearance is that ofauthentic swing-out doors but with the convenience of modern, upwardoperation. The steel base is available in Ultra-Grain® finish and solidcolors for the perfect complement to your home. The overlay materials are molded from actual wood to reproduce the natural texture and grain patterns of the species that they emulate. The combination of steel and overlay creates a distinct look.Canyon Ridge® Carriage House 4-Layer, Design 21; Shown in Ultra-Grain®Cypress Slate Finish with Clear Cypress Overlays and SQ24 Window Design; Rustic Collection Cherry Grain Fiberglass Entry Door with Clarion™ Clear Glass and SDL Grilles in Slate FinishCLASSIC andREFINEDWARRANTYLIFELIMITEDSTEEL PAINT SYSTEMWARRANTY5YRLIMITEDCOMPOSITE OVERLAY DELAMINATIONWARRANTY5YRLIMITEDHARDWARE4-LAYER CONSTRUCTIONColor Blast® finish offers more than 1,500 Sherwin-Williams®color options to complement your home. Clopay’s durable two-part paint system has been thoroughly tested and isbacked by a five-year warranty.CUSTOM PAINT OPTION13WINDOW/TOP SECTIONSTOP11 TOP12 TOP13 ARCH1 (Solid)Calculated door section R-value is in accordance with DASMA TDS-163.Canyon Ridge® doors not applicable for new construction in California areas designated as “Fire Hazard Severity Zones”.STYLE AND CONSTRUCTION■ 4-layer, faux-wood steel doors with Intellicore® polyurethane insulation.18.4 R-value.■ Multiple door designs and window options. Many custom designs alsoavailable. See your Clopay Dealer for more information.■ Insulated glass options include clear, frosted, seeded, rain and obscure.See page 45 for specialty glass options.■ Attractive beveled-edge, clip-in window grilles are removable for easy cleaning.■ Comes complete with spade lift handles and step plates.See pages 46–47 for details.COLORS Ultra-Grain® Cypress Walnut FinishWhite Finish* Ultra-Grain® Cypress Medium Finish Ultra-Grain Black Finish* ® Cypress Slate FinishMATERIAL DESIGN OPTIONS4LAYERCONSTRUCTIONDOOR DESIGNSSERIES 1Design 21 Design 22 Design 23SERIES 2Design 11 Design 12 Design 13All doors shown in Medium Finish with Clear Cypress overlays.Design 31 Design 32 Design 33 Design 34SERIES 3Design 35 Design 36 Design 37 Design 38Additional double width door designs available.Composite cladding is not present on Carriage House 4-Layer doors.*Black and White Finish available only on Mahogany overlays. Two-tone doors are available. To see all available options go to: dis.clopay.com. Steel surfaces have woodgrain texture. Doors can be ordered primed for those homeowners wishing to custom paint their doors. Note: Primed solid steel base is a brown color. Door stain color will vary slightly within a door due to finishing process. Due to the printing process, above colors may vary. Primed (No Finish)Clear CypressMahoganySTEEL BASE OVERLAYUltra-Grain® Finish Clear Cypress or Solid Color SteelREC11 REC13 REC14 SQ23 SQ24ARCH1 (Glass) ARCH3 ARCH4 ARC4A (Double Door)ARCH13 ARCH14 ARC14A (Double Door)COMPOSITE OVERLAY 112\POLYURETHANE INSULATION33STEEL WITH ULTRA-GRAIN®PAINT FINISH (SHOWN) OR SOLID COLOR STEEL224 STEEL4
