Recently Viewed Plans | Advanced Plan Search

Sq Ft
506 FT²

Beds
1

Baths
1

Stories
1

Garage
2

Depth
28'

Width
46'

From
$953.00

Front View

Rear View

View All 2 Images | Photographs may reflect modified home

Sq Ft

506 FT²

From

$953.00

Beds

Baths

Stories

Garage

Depth

28'

Width

46'

Modify

Cost Estimator

Sample Plan

Designer's Plan Details

Reverse Plan

Click to Zoom In on Floor Plan

1st Floor

About This Plan

This unique one-story house plan features equal parts home and garage, each with 506 square feet. The front houses a 2-car garage with both a large garage door and a side entrance for easy access. The back offers a cozy one-bedroom, one-bathroom home, perfect for efficient living. Ideal for those needing a functional space without sacrificing comfort, this plan can be tailored to suit your needs.

FEATURES & DETAILS

Kitchen features

Pantry

Bedroom features

Primary Bdrm Main Floor

Exterior features

Covered Front Porch

Lot Options

Suited for narrow lot

Additional features

Great Room
Laundry 1st Fl
Open Floor Plan

Garage Location

Front

Garage Options

Front-entry

506 Ft

Total Heated

Bedrooms

Bathrooms

Garage

Stories

46' 0"

Width

28' 0"

Depth

17' 1"

Height

9' 0"

Main Floor Ceiling

2x6

Framing

Truss

Roof Framing

9/12

Primary Roof Pitch

Single

Dwelling Number

Unheated Living Space

506 Ft

Garage

Exterior Styles

Cottage

Ranch

Traditional

Collections

Plan Package Options

Important info before you buy

Select Plan Package

$953

PDF Single Build

Digital plans emailed to you in PDF format that allows for printing copies and sharing electronically with contractors, subs, decorators, and more. This package includes a license to build the home one time.

$953

$1,153

5 Printed Sets

Five Printed Sets of Residential Construction Drawings are typically 24” x 36” documents and come with a license to construct a single residence shipped to a physical address. Keep in mind PDF Plan Packages are our most popular choice which allows you to print as many copies as you need and to electronically send files to your builder, subcontractors, etc.

$1,153

$1,203

5 Printed Sets + PDF

Digital plan emailed to you in PDF format that allows for printing copies on a home printer or local print shop and sharing with contractors, subs, decorators, and more. PLUS five printed sets shipped and delivered 3-5 business days.

$1,203

$1,906

CAD Single Build

2D electronic computer files, completely editable, for design professional use, when making extensive modifications or in the event engineering is required in the area where you are building.

$1,906

Need To Reverse Plan? (Optional)

$225

Readable Reverse

Reverse house plans with readable text and dimensions

$225

Select Foundation Option

Add-Ons (Optional)

INCLUDED WITH YOUR PURCHASE

	Free Ground shipping in the Continental U.S.	FREE
	Design consultation with the architect or designer to discuss your plan
	Home Building & Product Ideas Organizer

Sub Total

$0
Free Shipping

ADD TO CART

QUESTIONS OR NEED HELP ORDERING? LIVE CHAT OR CALL US AT 866-214-2242

Plan Packages

Each set of construction documents includes detailed, dimensioned floor plans, basic electric layouts, cross sections, roof details, cabinet layouts and elevations, as well as general IRC specifications. They contain virtually all of the information required to construct your home. The typical plan set does not include any plumbing, HVAC drawings, or engineering stamps due to the wide variety of specific needs, local codes, and climatic conditions. These details and specifications are easily obtained from your builder, contractor, and/or local engineers.
