HOUSE PLANS SALE
START AT $765.00
SQ FT
1,392
BEDS
3
BATHS
2
STORIES
1
CARS
2
WIDTH
47'
DEPTH
72'
© copyright by designer
Photographs may reflect modified home | View all 5 images
SQ FT
1,392
BEDS
3
BATHS
2
STORIES
1
CARS
2

House Plan 5287: Lexington 1316

Small and compact, this home has all of the amenities of luxury homes making it perfect for those empty nesters that want to scale back. The living, dining and kitchen areas are very open and bright creating the sense of a much larger space. The raised ceiling in the living room adds to that open feeling and the light of the French doors further enhances the space. The built in book shelves on each side of the fireplace will provide you with tons of space for all the books and photographs that you have collected over a lifetime. Typical ceiling heights are 9’ and more typical of larger homes. The kitchen overlooks the living and dining area and it has a large island with an eating bar. Double French doors open from the dining room and right into the large rear covered porch and entertainment area. The outdoor kitchen provides the finishing touch for entertaining your guest. Now that you have plenty of time to play golf, there is a golf cart storage area in the garage or it can be used for lawn tractors or other storage. The master suite has double French doors for easy access to the rear covered porch. The bath is exceptional for this size home and features twin vanities, spa tub, separate shower and a giant walk-in closet. A large painted glass window located above the spa tub bathes the bath with soft lighting from the outside.

With its charming exterior styling and its thoroughly modern interior, this is a great starter home too. The small foot print will fit well on smaller lots and the low square footage combines to make this a very affordable home. This is a super energy saving home designed to slash heating and cooling cost by 50% but without increasing the cost of building. Regardless if you are looking to downsize or if you’re looking for that perfect first home, this plan has it all.

Click to Zoom In on Floor Plan
Floor Plans
© copyright by designer
Plan Packages
 Select Plan Package
PDF Bid Set

Home plans stamped "NOT FOR CONSTRUCTION" for cost estimating and bidding purposes only; a minimum 5 set plan package must be purchased within 90 days for a license to build plan set; a credit will be applied towards your house plan upgrade

PDF Bid Set
PDFs NOW!™
Digital set of plans for bidding purposes only
$700
PDF Single Build

Digital plans emailed to you in PDF format that allows for printing copies and sharing electronically with contractors, subs, decorators, and more. This package includes a license to build the home one time.

PDF Single Build
PDFs NOW!™
Most recommended package
$900
4 Printed Sets

Four printed sets of construction drawings shipped and received in 3-5 business days

4 Printed Sets
Four printed sets of house plans
$1,005
5 Printed Sets

Five Printed Sets of Residential Construction Drawings are typically 24” x 36” documents and come with a license to construct a single residence shipped to a physical address. Keep in mind PDF Plan Packages are our most popular choice which allows you to print as many copies as you need and to electronically send files to your builder, subcontractors, etc.

5 Printed Sets
Five printed sets of house plans
$1,050
8 Printed Sets

Eight Printed Sets of Construction Drawings, typically 24” x 36” documents, with a license to construct a single residence shipped to your physical address. PDF Plan Packages are our most popular choice which allows you to print as many copies as you need and to electronically send files to your builder, subcontractors, bank/mortgage reps, material stores, decorators and more.

8 Printed Sets
Eight printed sets of house plans
$1,110
8 Printed Sets + PDF

Digital plan emailed to you in PDF format that allows for printing copies on a home printer or local print shop and sharing with contractors, subs, decorators, and more. PLUS eight printed sets shipped and delivered 3-5 business days.

8 Printed Sets + PDF
PDFs NOW!™
Digital plans plus 8 printed sets
$1,160
CAD Single Build

2D electronic computer files, completely editable, for design professional use, when making extensive modifications or in the event engineering is required in the area where you are building.

CAD Single Build
2D electronic editable computer files
$1,600
 Need To Reverse Plan? (Optional)

Readable Reverse


Reverse house plans with readable text and dimensions

Readable Reverse
Reverses house plans with readable text and dimensions
$125
 Select Foundation Option
 Add-Ons (Optional)
Subtotal:
$0
Free Shipping
Features:
View All Plan Features
Kitchen features
Peninsula / Eating Bar
Bedroom features
Master Bdrm Main Floor
Separate Tub and Shower
Walk-in Closet
Additional features
Dining Room
Fireplace
Formal LR
Laundry 1st Fl
Open Floor Plan
Exterior features
Covered Front Porch
Covered Rear Porch
Front Porch
Rear Porch
Garage Location
Rear
Garage Options
Attached
Oversized
Side-entry
Foundation Options
Slab
Lot Options
Suited for corner lot
Suited for narrow lot

Hide Plan Features
Details:
View All Plan Details
2,463 Ft
2
Total Structure:
1,392 Ft
2
Total Heated:
3
Bedrooms:
2
Bathrooms:
2
Garage:
1
Stories:
47' 0"
Width:
72' 0"
Depth:
29' 0"
Height:
9 & 11' 0"
Main Floor Ceiling:
2x6
Framing:
Stick
Roof Framing:
12;12
Primary Roof Pitch:
7:12
Secondary Roof Pitch:
12:12
Dormer Roof Pitch:
12:12
Porch Roof Pitch:
Single
Dwelling Number:
Unheated Living Space
607 Ft
2
Garage:
464 Ft
2
Porch:
Exterior Styles
Cottage
Country
Southern
Traditional
Collections
Builders
Old House Classics
Open Floor Plan
Outdoor Living

Hide Plan Details
